Galaxy Tab A7 10.4 (2022) SM-T509 Specifications

Galaxy Tab A7 10.4 (2022) SM-T509 Specifications
Brand: Samsung Category: Mobile
  • Display 10.4 inches, 1200 x 2000 pixels
  • Camera Rear Cameras: 8 MP / Selfie Camera: 5MP
  • CPU Octa-core (2x2.0 GHz Cortex-A75 & 6x1.8 GHz Cortex-A55), Unisoc UMS512 T618 (12 nm)
  • RAM 3GB, 4GB
  • Storage 32GB, 64GB
  • Battery 7040 mAh, Non-removable,
  • OS Android 12, One UI 4

Specs

What is this device?

Model Name Galaxy Tab A7 10.4 (2022)
Brand <abbr title="Brand">Manufacturer name</abbr> Samsung
Model Numbers SM-T509
Date of released 21 November, 2025

Design

Size (width x height) 247.6 x 157.4 mm (9.75 x 6.20 in)
Depth 7 mm (0.28 in)
Weight 477 g (1.05 lb)
Materials Glass front, plastic frame, plastic back
Colors Dark Gray, Silver, Gold

Operating System

OS Version Android 12
Upgradable Android 13
Skin (User Interface) One UI 4

Processor

Chipset Unisoc UMS512 T618 (12 nm)
CPU (Processor) Octa-core (2x2.0 GHz Cortex-A75 and 6x1.8 GHz Cortex-A55)
GPU Mali G52 MP2

Memory

RAM 3GB, 4GB
Internal storage 32GB, 64GB
External Card Slot
Memory Card slot type microSDXC (dedicated slot)

Display

Technology (Type) TFT LCD
Screen size 10.4 inches, 307.9 cm2
Resolution 1200 x 2000 pixels
Screen to body ratio 79.0%
Pixel density 224 ppi density (19.5:9 ratio)

SIM and Network

SIM Hybrid Dual SIM (Nano-SIM, dual stand-by)
SIM type Nano-SIM
Data Speed GSM / HSPA / LTE
Network technology HSPA, LTE-A
2G bands GSM 850 / 900 / 1800 / 1900
3G bands HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
4G bands LTE
5G bands HSPA 42.2/5.76 Mbps, LTE-A (2CA) Cat13 400/50 Mbps
View More View Less

Front Camera (Selfie)

Front camera Singal
Resolution 5 MP
Video 1080p@30fps
Flash Not supported
View More View Less

Main Camera (Back)

Number of cameras Singal
Main camera 8 MP
Video 1080p@30fps
Flash LED flash
Touch focus
Image stabilization
HDR Yes
BSI sensor Not Supported
View More View Less

Battery

Battery type Li-Po (lithium-polymer battery)
Capacity 7040 mAh
Charging 15W wired
Removal status non-removable

Sound

Headphones jack 3.5mm jack
Speakers Single speakers
Radio
Audio formats MP3, WAV, WMA, eAAC+, FLAC
Video formats MP4, H.265, H.264, H.263, XviD, MKV

Connectivity

Bluetooth 5.0, A2DP, LE
WiFi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct
USB USB Type-C 2.0
Audio output 3.5mm jack
DLNA Supported
GPS GPS, GLONASS, GALILEO, BDS, QZSS
NFC Supported
View More View Less

Sensors

Sensors Accelerometer, gyro, proximity, compass
Vibrating alert

More

Call control Voice dialing, Voice recorder, Voice commands
Messaging SMS (T9), MMS, E-mail, Push mail
Web browser HTML, XHTML, HTML5
In The Box UBS-C cable, User manual, SIM eject tool
